| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2131-024-1204-P2280-X | 2200K | 80 | 0 | 1653 | 1777 | 145 | 34.0 |
| P2131-024-1204-P2580-X | 2500K | 0 | 1715 | 1845 | 151 | 34.0 | |
| P2131-024-1204-P2780-X | 2700K | 0 | 1778 | 1912 | 156 | 34.0 | |
| P2131-024-1204-P3080-X | 3000K | 0 | 1878 | 2020 | 165 | 34.0 | |
| P2131-024-1204-P3580-X | 3500K | 0 | 1928 | 2073 | 169 | 34.0 | |
| P2131-024-1204-P4080-X | 4000K | 0 | 1978 | 2127 | 174 | 34.0 | |
| P2131-024-1204-P4580-X | 4500K | 0 | 1991 | 2141 | 175 | 34.0 | |
| P2131-024-1204-P5080-X | 5000K | 0 | 2003 | 2154 | 176 | 34.0 | |
| P2131-024-1204-P5780-X | 5700K | 0 | 2003 | 2154 | 176 | 34.0 | |
| P2131-024-1204-P6580-X | 6500K | 0 | 1978 | 2127 | 174 | 34.0 | |
| P2131-024-1204-P2290-X | 2200K | 90 | 50 | 1390 | 1495 | 122 | 34.0 |
| P2131-024-1204-P2590-X | 2500K | 50 | 1452 | 1562 | 128 | 34.0 | |
| P2131-024-1204-P2790-X | 2700K | 50 | 1515 | 1629 | 133 | 34.0 | |
| P2131-024-1204-P3090-X | 3000K | 50 | 1603 | 1723 | 141 | 34.0 | |
| P2131-024-1204-P3590-X | 3500K | 50 | 1653 | 1777 | 145 | 34.0 | |
| P2131-024-1204-P4090-X | 4000K | 50 | 1678 | 1804 | 147 | 34.0 | |
| P2131-024-1204-P4590-X | 4500K | 50 | 1697 | 1824 | 149 | 34.0 | |
| P2131-024-1204-P5090-X | 5000K | 50 | 1715 | 1845 | 151 | 34.0 | |
| P2131-024-1204-P5790-X | 5700K | 50 | 1715 | 1845 | 151 | 34.0 | |
| P2131-024-1204-P6590-X | 6500K | 50 | 1690 | 1818 | 149 | 34.0 | |
| P2131-024-1204-P2797-X | 2700K | 97 | 90 | 1182 | 1271 | 104 | 34.0 |
| P2131-024-1204-P3097-X | 3000K | 90 | 1282 | 1378 | 113 | 34.0 | |
| P2131-024-1204-P3597-X | 3500K | 85 | 1332 | 1432 | 117 | 34.0 | |
| P2131-024-1204-P4097-X | 4000K | 85 | 1382 | 1486 | 121 | 34.0 | |
| P2131-024-1204-P4595-X | 4500K | 95 | 80 | 1442 | 1551 | 127 | 34.0 |
| P2131-024-1204-P5095-X | 5000K | 80 | 1458 | 1568 | 128 | 34.0 | |
