| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2141-040-1207-P2280-X | 2200K | 80 | 0 | 2937 | 3158 | 147 | 34.0 |
| P2141-040-1207-P2580-X | 2500K | 0 | 3046 | 3276 | 153 | 34.0 | |
| P2141-040-1207-P2780-X | 2700K | 0 | 3156 | 3393 | 158 | 34.0 | |
| P2141-040-1207-P3080-X | 3000K | 0 | 3331 | 3582 | 167 | 34.0 | |
| P2141-040-1207-P3580-X | 3500K | 0 | 3419 | 3676 | 172 | 34.0 | |
| P2141-040-1207-P4080-X | 4000K | 0 | 3506 | 3770 | 176 | 34.0 | |
| P2141-040-1207-P4580-X | 4500K | 0 | 3528 | 3794 | 177 | 34.0 | |
| P2141-040-1207-P5080-X | 5000K | 0 | 3550 | 3818 | 178 | 34.0 | |
| P2141-040-1207-P5780-X | 5700K | 0 | 3550 | 3818 | 178 | 34.0 | |
| P2141-040-1207-P6580-X | 6500K | 0 | 3506 | 3770 | 176 | 34.0 | |
| P2141-040-1207-P2290-X | 2200K | 90 | 50 | 2477 | 2663 | 124 | 34.0 |
| P2141-040-1207-P2590-X | 2500K | 50 | 2586 | 2781 | 130 | 34.0 | |
| P2141-040-1207-P2790-X | 2700K | 50 | 2696 | 2899 | 135 | 34.0 | |
| P2141-040-1207-P3090-X | 3000K | 50 | 2849 | 3064 | 143 | 34.0 | |
| P2141-040-1207-P3590-X | 3500K | 50 | 2937 | 3158 | 147 | 34.0 | |
| P2141-040-1207-P4090-X | 4000K | 50 | 2981 | 3205 | 150 | 34.0 | |
| P2141-040-1207-P4590-X | 4500K | 50 | 3013 | 3240 | 151 | 34.0 | |
| P2141-040-1207-P5090-X | 5000K | 50 | 3046 | 3276 | 153 | 34.0 | |
| P2141-040-1207-P5790-X | 5700K | 50 | 3046 | 3276 | 153 | 34.0 | |
| P2141-040-1207-P6590-X | 6500K | 50 | 3002 | 3228 | 151 | 34.0 | |
| P2141-040-1207-P2797-X | 2700K | 97 | 90 | 2112 | 2271 | 106 | 34.0 |
| P2141-040-1207-P3097-X | 3000K | 90 | 2288 | 2460 | 115 | 34.0 | |
| P2141-040-1207-P3597-X | 3500K | 85 | 2375 | 2554 | 119 | 34.0 | |
| P2141-040-1207-P4097-X | 4000K | 85 | 2463 | 2648 | 124 | 34.0 | |
| P2141-040-1207-P4595-X | 4500K | 95 | 80 | 2568 | 2761 | 129 | 34.0 |
| P2141-040-1207-P5095-X | 5000K | 80 | 2596 | 2791 | 130 | 34.0 | |
