| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2142-040-1207-P2280-X | 2200K | 80 | 0 | 2871 | 3087 | 144 | 34.0 |
| P2142-040-1207-P2580-X | 2500K | 0 | 2981 | 3205 | 150 | 34.0 | |
| P2142-040-1207-P2780-X | 2700K | 0 | 3090 | 3323 | 155 | 34.0 | |
| P2142-040-1207-P3080-X | 3000K | 0 | 3265 | 3511 | 164 | 34.0 | |
| P2142-040-1207-P3580-X | 3500K | 0 | 3353 | 3605 | 168 | 34.0 | |
| P2142-040-1207-P4080-X | 4000K | 0 | 3441 | 3700 | 173 | 34.0 | |
| P2142-040-1207-P4580-X | 4500K | 0 | 3463 | 3723 | 174 | 34.0 | |
| P2142-040-1207-P5080-X | 5000K | 0 | 3485 | 3747 | 175 | 34.0 | |
| P2142-040-1207-P5780-X | 5700K | 0 | 3485 | 3747 | 175 | 34.0 | |
| P2142-040-1207-P6580-X | 6500K | 0 | 3441 | 3700 | 173 | 34.0 | |
| P2142-040-1207-P2290-X | 2200K | 90 | 50 | 2411 | 2592 | 121 | 34.0 |
| P2142-040-1207-P2590-X | 2500K | 50 | 2520 | 2710 | 127 | 34.0 | |
| P2142-040-1207-P2790-X | 2700K | 50 | 2630 | 2828 | 132 | 34.0 | |
| P2142-040-1207-P3090-X | 3000K | 50 | 2783 | 2993 | 140 | 34.0 | |
| P2142-040-1207-P3590-X | 3500K | 50 | 2871 | 3087 | 144 | 34.0 | |
| P2142-040-1207-P4090-X | 4000K | 50 | 2915 | 3134 | 146 | 34.0 | |
| P2142-040-1207-P4590-X | 4500K | 50 | 2948 | 3170 | 148 | 34.0 | |
| P2142-040-1207-P5090-X | 5000K | 50 | 2981 | 3205 | 150 | 34.0 | |
| P2142-040-1207-P5790-X | 5700K | 50 | 2981 | 3205 | 150 | 34.0 | |
| P2142-040-1207-P6590-X | 6500K | 50 | 2937 | 3158 | 147 | 34.0 | |
| P2142-040-1207-P2797-X | 2700K | 97 | 90 | 2061 | 2216 | 103 | 34.0 |
| P2142-040-1207-P3097-X | 3000K | 90 | 2236 | 2405 | 112 | 34.0 | |
| P2142-040-1207-P3597-X | 3500K | 85 | 2324 | 2499 | 117 | 34.0 | |
| P2142-040-1207-P4097-X | 4000K | 85 | 2412 | 2593 | 121 | 34.0 | |
| P2142-040-1207-P4595-X | 4500K | 95 | 80 | 2512 | 2701 | 126 | 34.0 |
| P2142-040-1207-P5095-X | 5000K | 80 | 2540 | 2731 | 128 | 34.0 | |
