| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2151-030-1205-P2280-X | 2200K | 80 | 0 | 2035 | 2188 | 143 | 34.0 |
| P2151-030-1205-P2580-X | 2500K | 0 | 2113 | 2272 | 149 | 34.0 | |
| P2151-030-1205-P2780-X | 2700K | 0 | 2191 | 2356 | 154 | 34.0 | |
| P2151-030-1205-P3080-X | 3000K | 0 | 2316 | 2491 | 163 | 34.0 | |
| P2151-030-1205-P3580-X | 3500K | 0 | 2379 | 2558 | 167 | 34.0 | |
| P2151-030-1205-P4080-X | 4000K | 0 | 2442 | 2625 | 172 | 34.0 | |
| P2151-030-1205-P4580-X | 4500K | 0 | 2457 | 2642 | 173 | 34.0 | |
| P2151-030-1205-P5080-X | 5000K | 0 | 2473 | 2659 | 174 | 34.0 | |
| P2151-030-1205-P5780-X | 5700K | 0 | 2473 | 2659 | 174 | 34.0 | |
| P2151-030-1205-P6580-X | 6500K | 0 | 2442 | 2625 | 172 | 34.0 | |
| P2151-030-1205-P2290-X | 2200K | 90 | 50 | 1706 | 1834 | 120 | 34.0 |
| P2151-030-1205-P2590-X | 2500K | 50 | 1784 | 1919 | 125 | 34.0 | |
| P2151-030-1205-P2790-X | 2700K | 50 | 1863 | 2003 | 131 | 34.0 | |
| P2151-030-1205-P3090-X | 3000K | 50 | 1972 | 2121 | 139 | 34.0 | |
| P2151-030-1205-P3590-X | 3500K | 50 | 2035 | 2188 | 143 | 34.0 | |
| P2151-030-1205-P4090-X | 4000K | 50 | 2066 | 2222 | 145 | 34.0 | |
| P2151-030-1205-P4590-X | 4500K | 50 | 2090 | 2247 | 147 | 34.0 | |
| P2151-030-1205-P5090-X | 5000K | 50 | 2113 | 2272 | 149 | 34.0 | |
| P2151-030-1205-P5790-X | 5700K | 50 | 2113 | 2272 | 149 | 34.0 | |
| P2151-030-1205-P6590-X | 6500K | 50 | 2082 | 2238 | 146 | 34.0 | |
| P2151-030-1205-P2797-X | 2700K | 97 | 90 | 1453 | 1562 | 102 | 34.0 |
| P2151-030-1205-P3097-X | 3000K | 90 | 1578 | 1697 | 111 | 34.0 | |
| P2151-030-1205-P3597-X | 3500K | 85 | 1641 | 1764 | 115 | 34.0 | |
| P2151-030-1205-P4097-X | 4000K | 85 | 1703 | 1831 | 120 | 34.0 | |
| P2151-030-1205-P4595-X | 4500K | 95 | 80 | 1776 | 1910 | 125 | 34.0 |
| P2151-030-1205-P5095-X | 5000K | 80 | 1796 | 1931 | 126 | 34.0 | |
