| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2151-036-1206-P2280-X | 2200K | 80 | 0 | 2423 | 2605 | 142 | 34.0 |
| P2151-036-1206-P2580-X | 2500K | 0 | 2517 | 2706 | 147 | 34.0 | |
| P2151-036-1206-P2780-X | 2700K | 0 | 2611 | 2807 | 153 | 34.0 | |
| P2151-036-1206-P3080-X | 3000K | 0 | 2761 | 2969 | 162 | 34.0 | |
| P2151-036-1206-P3580-X | 3500K | 0 | 2836 | 3050 | 166 | 34.0 | |
| P2151-036-1206-P4080-X | 4000K | 0 | 2911 | 3130 | 171 | 34.0 | |
| P2151-036-1206-P4580-X | 4500K | 0 | 2930 | 3151 | 172 | 34.0 | |
| P2151-036-1206-P5080-X | 5000K | 0 | 2949 | 3171 | 173 | 34.0 | |
| P2151-036-1206-P5780-X | 5700K | 0 | 2949 | 3171 | 173 | 34.0 | |
| P2151-036-1206-P6580-X | 6500K | 0 | 2911 | 3130 | 171 | 34.0 | |
| P2151-036-1206-P2290-X | 2200K | 90 | 50 | 2028 | 2181 | 119 | 34.0 |
| P2151-036-1206-P2590-X | 2500K | 50 | 2122 | 2282 | 124 | 34.0 | |
| P2151-036-1206-P2790-X | 2700K | 50 | 2216 | 2383 | 130 | 34.0 | |
| P2151-036-1206-P3090-X | 3000K | 50 | 2348 | 2525 | 138 | 34.0 | |
| P2151-036-1206-P3590-X | 3500K | 50 | 2423 | 2605 | 142 | 34.0 | |
| P2151-036-1206-P4090-X | 4000K | 50 | 2460 | 2646 | 144 | 34.0 | |
| P2151-036-1206-P4590-X | 4500K | 50 | 2489 | 2676 | 146 | 34.0 | |
| P2151-036-1206-P5090-X | 5000K | 50 | 2517 | 2706 | 147 | 34.0 | |
| P2151-036-1206-P5790-X | 5700K | 50 | 2517 | 2706 | 147 | 34.0 | |
| P2151-036-1206-P6590-X | 6500K | 50 | 2479 | 2666 | 145 | 34.0 | |
| P2151-036-1206-P2797-X | 2700K | 97 | 90 | 1729 | 1859 | 101 | 34.0 |
| P2151-036-1206-P3097-X | 3000K | 90 | 1879 | 2020 | 110 | 34.0 | |
| P2151-036-1206-P3597-X | 3500K | 85 | 1954 | 2101 | 114 | 34.0 | |
| P2151-036-1206-P4097-X | 4000K | 85 | 2029 | 2182 | 119 | 34.0 | |
| P2151-036-1206-P4595-X | 4500K | 95 | 80 | 2115 | 2275 | 124 | 34.0 |
| P2151-036-1206-P5095-X | 5000K | 80 | 2139 | 2300 | 125 | 34.0 | |
