| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2152-050-1208-P2280-X | 2200K | 80 | 0 | 3256 | 3501 | 143 | 34.0 |
| P2152-050-1208-P2580-X | 2500K | 0 | 3381 | 3635 | 149 | 34.0 | |
| P2152-050-1208-P2780-X | 2700K | 0 | 3506 | 3770 | 154 | 34.0 | |
| P2152-050-1208-P3080-X | 3000K | 0 | 3706 | 3985 | 163 | 34.0 | |
| P2152-050-1208-P3580-X | 3500K | 0 | 3807 | 4093 | 167 | 34.0 | |
| P2152-050-1208-P4080-X | 4000K | 0 | 3907 | 4201 | 172 | 34.0 | |
| P2152-050-1208-P4580-X | 4500K | 0 | 3932 | 4228 | 173 | 34.0 | |
| P2152-050-1208-P5080-X | 5000K | 0 | 3957 | 4255 | 174 | 34.0 | |
| P2152-050-1208-P5780-X | 5700K | 0 | 3957 | 4255 | 174 | 34.0 | |
| P2152-050-1208-P6580-X | 6500K | 0 | 3907 | 4201 | 172 | 34.0 | |
| P2152-050-1208-P2290-X | 2200K | 90 | 50 | 2730 | 2935 | 120 | 34.0 |
| P2152-050-1208-P2590-X | 2500K | 50 | 2855 | 3070 | 125 | 34.0 | |
| P2152-050-1208-P2790-X | 2700K | 50 | 2980 | 3204 | 131 | 34.0 | |
| P2152-050-1208-P3090-X | 3000K | 50 | 3155 | 3393 | 139 | 34.0 | |
| P2152-050-1208-P3590-X | 3500K | 50 | 3256 | 3501 | 143 | 34.0 | |
| P2152-050-1208-P4090-X | 4000K | 50 | 3306 | 3554 | 145 | 34.0 | |
| P2152-050-1208-P4590-X | 4500K | 50 | 3343 | 3595 | 147 | 34.0 | |
| P2152-050-1208-P5090-X | 5000K | 50 | 3381 | 3635 | 149 | 34.0 | |
| P2152-050-1208-P5790-X | 5700K | 50 | 3381 | 3635 | 149 | 34.0 | |
| P2152-050-1208-P6590-X | 6500K | 50 | 3331 | 3581 | 146 | 34.0 | |
| P2152-050-1208-P2797-X | 2700K | 97 | 90 | 2324 | 2499 | 102 | 34.0 |
| P2152-050-1208-P3097-X | 3000K | 90 | 2525 | 2715 | 111 | 34.0 | |
| P2152-050-1208-P3597-X | 3500K | 85 | 2625 | 2823 | 115 | 34.0 | |
| P2152-050-1208-P4097-X | 4000K | 85 | 2725 | 2930 | 120 | 34.0 | |
| P2152-050-1208-P4595-X | 4500K | 95 | 80 | 2842 | 3056 | 125 | 34.0 |
| P2152-050-1208-P5095-X | 5000K | 80 | 2874 | 3090 | 126 | 34.0 | |
