| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2171-060-1210-P2280-X | 2200K | 80 | 0 | 4289 | 4611 | 151 | 34.0 |
| P2171-060-1210-P2580-X | 2500K | 0 | 4445 | 4780 | 156 | 34.0 | |
| P2171-060-1210-P2780-X | 2700K | 0 | 4602 | 4948 | 162 | 34.0 | |
| P2171-060-1210-P3080-X | 3000K | 0 | 4852 | 5217 | 171 | 34.0 | |
| P2171-060-1210-P3580-X | 3500K | 0 | 4977 | 5352 | 175 | 34.0 | |
| P2171-060-1210-P4080-X | 4000K | 0 | 5103 | 5487 | 179 | 34.0 | |
| P2171-060-1210-P4580-X | 4500K | 0 | 5134 | 5520 | 180 | 34.0 | |
| P2171-060-1210-P5080-X | 5000K | 0 | 5165 | 5554 | 182 | 34.0 | |
| P2171-060-1210-P5780-X | 5700K | 0 | 5165 | 5554 | 182 | 34.0 | |
| P2171-060-1210-P6580-X | 6500K | 0 | 5103 | 5487 | 179 | 34.0 | |
| P2171-060-1210-P2290-X | 2200K | 90 | 50 | 3631 | 3905 | 128 | 34.0 |
| P2171-060-1210-P2590-X | 2500K | 50 | 3788 | 4073 | 133 | 34.0 | |
| P2171-060-1210-P2790-X | 2700K | 50 | 3944 | 4241 | 139 | 34.0 | |
| P2171-060-1210-P3090-X | 3000K | 50 | 4163 | 4477 | 146 | 34.0 | |
| P2171-060-1210-P3590-X | 3500K | 50 | 4289 | 4611 | 151 | 34.0 | |
| P2171-060-1210-P4090-X | 4000K | 50 | 4351 | 4679 | 153 | 34.0 | |
| P2171-060-1210-P4590-X | 4500K | 50 | 4398 | 4729 | 155 | 34.0 | |
| P2171-060-1210-P5090-X | 5000K | 50 | 4445 | 4780 | 156 | 34.0 | |
| P2171-060-1210-P5790-X | 5700K | 50 | 4445 | 4780 | 156 | 34.0 | |
| P2171-060-1210-P6590-X | 6500K | 50 | 4383 | 4712 | 154 | 34.0 | |
| P2171-060-1210-P2797-X | 2700K | 97 | 90 | 3077 | 3308 | 108 | 34.0 |
| P2171-060-1210-P3097-X | 3000K | 90 | 3327 | 3577 | 117 | 34.0 | |
| P2171-060-1210-P3597-X | 3500K | 85 | 3452 | 3712 | 121 | 34.0 | |
| P2171-060-1210-P4097-X | 4000K | 85 | 3577 | 3847 | 126 | 34.0 | |
| P2171-060-1210-P4595-X | 4500K | 95 | 80 | 3738 | 4020 | 131 | 34.0 |
| P2171-060-1210-P5095-X | 5000K | 80 | 3778 | 4063 | 133 | 34.0 | |
