| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2171-072-1212-P2280-X | 2200K | 80 | 0 | 5109 | 5493 | 150 | 34.0 |
| P2171-072-1212-P2580-X | 2500K | 0 | 5297 | 5695 | 155 | 34.0 | |
| P2171-072-1212-P2780-X | 2700K | 0 | 5484 | 5897 | 161 | 34.0 | |
| P2171-072-1212-P3080-X | 3000K | 0 | 5785 | 6220 | 169 | 34.0 | |
| P2171-072-1212-P3580-X | 3500K | 0 | 5935 | 6382 | 174 | 34.0 | |
| P2171-072-1212-P4080-X | 4000K | 0 | 6085 | 6544 | 178 | 34.0 | |
| P2171-072-1212-P4580-X | 4500K | 0 | 6123 | 6584 | 179 | 34.0 | |
| P2171-072-1212-P5080-X | 5000K | 0 | 6161 | 6624 | 180 | 34.0 | |
| P2171-072-1212-P5780-X | 5700K | 0 | 6161 | 6624 | 180 | 34.0 | |
| P2171-072-1212-P6580-X | 6500K | 0 | 6085 | 6544 | 178 | 34.0 | |
| P2171-072-1212-P2290-X | 2200K | 90 | 50 | 4320 | 4645 | 127 | 34.0 |
| P2171-072-1212-P2590-X | 2500K | 50 | 4508 | 4847 | 132 | 34.0 | |
| P2171-072-1212-P2790-X | 2700K | 50 | 4696 | 5049 | 138 | 34.0 | |
| P2171-072-1212-P3090-X | 3000K | 50 | 4959 | 5332 | 145 | 34.0 | |
| P2171-072-1212-P3590-X | 3500K | 50 | 5109 | 5493 | 150 | 34.0 | |
| P2171-072-1212-P4090-X | 4000K | 50 | 5184 | 5574 | 152 | 34.0 | |
| P2171-072-1212-P4590-X | 4500K | 50 | 5240 | 5635 | 153 | 34.0 | |
| P2171-072-1212-P5090-X | 5000K | 50 | 5297 | 5695 | 155 | 34.0 | |
| P2171-072-1212-P5790-X | 5700K | 50 | 5297 | 5695 | 155 | 34.0 | |
| P2171-072-1212-P6590-X | 6500K | 50 | 5221 | 5614 | 153 | 34.0 | |
| P2171-072-1212-P2797-X | 2700K | 97 | 90 | 3663 | 3938 | 107 | 34.0 |
| P2171-072-1212-P3097-X | 3000K | 90 | 3963 | 4261 | 116 | 34.0 | |
| P2171-072-1212-P3597-X | 3500K | 85 | 4113 | 4423 | 120 | 34.0 | |
| P2171-072-1212-P4097-X | 4000K | 85 | 4264 | 4584 | 125 | 34.0 | |
| P2171-072-1212-P4595-X | 4500K | 95 | 80 | 4454 | 4789 | 130 | 34.0 |
| P2171-072-1212-P5095-X | 5000K | 80 | 4502 | 4841 | 132 | 34.0 | |
