| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P2181-110-1812-P2280-X | 2200K | 80 | 0 | 7552 | 8120 | 147 | 34.0 |
| P2181-110-1812-P2580-X | 2500K | 0 | 7833 | 8423 | 153 | 34.0 | |
| P2181-110-1812-P2780-X | 2700K | 0 | 8115 | 8726 | 158 | 34.0 | |
| P2181-110-1812-P3080-X | 3000K | 0 | 8566 | 9211 | 167 | 34.0 | |
| P2181-110-1812-P3580-X | 3500K | 0 | 8791 | 9453 | 172 | 34.0 | |
| P2181-110-1812-P4080-X | 4000K | 0 | 9017 | 9695 | 176 | 34.0 | |
| P2181-110-1812-P4580-X | 4500K | 0 | 9073 | 9756 | 177 | 34.0 | |
| P2181-110-1812-P5080-X | 5000K | 0 | 9129 | 9816 | 178 | 34.0 | |
| P2181-110-1812-P5780-X | 5700K | 0 | 9129 | 9816 | 178 | 34.0 | |
| P2181-110-1812-P6580-X | 6500K | 0 | 9017 | 9695 | 176 | 34.0 | |
| P2181-110-1812-P2290-X | 2200K | 90 | 50 | 6368 | 6848 | 124 | 34.0 |
| P2181-110-1812-P2590-X | 2500K | 50 | 6650 | 7151 | 130 | 34.0 | |
| P2181-110-1812-P2790-X | 2700K | 50 | 6932 | 7454 | 135 | 34.0 | |
| P2181-110-1812-P3090-X | 3000K | 50 | 7326 | 7878 | 143 | 34.0 | |
| P2181-110-1812-P3590-X | 3500K | 50 | 7552 | 8120 | 147 | 34.0 | |
| P2181-110-1812-P4090-X | 4000K | 50 | 7664 | 8241 | 150 | 34.0 | |
| P2181-110-1812-P4590-X | 4500K | 50 | 7749 | 8332 | 151 | 34.0 | |
| P2181-110-1812-P5090-X | 5000K | 50 | 7833 | 8423 | 153 | 34.0 | |
| P2181-110-1812-P5790-X | 5700K | 50 | 7833 | 8423 | 153 | 34.0 | |
| P2181-110-1812-P6590-X | 6500K | 50 | 7721 | 8302 | 151 | 34.0 | |
| P2181-110-1812-P2797-X | 2700K | 97 | 90 | 5432 | 5841 | 106 | 34.0 |
| P2181-110-1812-P3097-X | 3000K | 90 | 5883 | 6325 | 115 | 34.0 | |
| P2181-110-1812-P3597-X | 3500K | 85 | 6108 | 6568 | 119 | 34.0 | |
| P2181-110-1812-P4097-X | 4000K | 85 | 6333 | 6810 | 124 | 34.0 | |
| P2181-110-1812-P4595-X | 4500K | 95 | 80 | 6604 | 7101 | 129 | 34.0 |
| P2181-110-1812-P5095-X | 5000K | 80 | 6675 | 7178 | 130 | 34.0 | |
