| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P4111-006-0304-P2280-X | 2200K | 80 | 0 | 460 | 495 | 162 | 8.5 |
| P4111-006-0304-P2580-X | 2500K | 80 | 0 | 476 | 512 | 167 | 8.5 |
| P4111-006-0304-P2780-X | 2700K | 80 | 0 | 491 | 528 | 173 | 8.5 |
| P4111-006-0304-P3080-X | 3000K | 80 | 0 | 516 | 555 | 181 | 8.5 |
| P4111-006-0304-P3580-X | 3500K | 80 | 0 | 526 | 565 | 185 | 8.5 |
| P4111-006-0304-P4080-X | 4000K | 80 | 0 | 541 | 581 | 190 | 8.5 |
| P4111-006-0304-P4580-X | 4500K | 80 | 0 | 544 | 585 | 191 | 8.5 |
| P4111-006-0304-P5080-X | 5000K | 80 | 0 | 548 | 589 | 193 | 8.5 |
| P4111-006-0304-P5780-X | 5700K | 80 | 0 | 548 | 589 | 193 | 8.5 |
| P4111-006-0304-P6580-X | 6500K | 80 | 0 | 541 | 581 | 190 | 8.5 |
| P4111-006-0304-P2290-X | 2200K | 90 | 50 | 386 | 416 | 136 | 8.5 |
| P4111-006-0304-P2590-X | 2500K | 90 | 50 | 402 | 432 | 141 | 8.5 |
| P4111-006-0304-P2790-X | 2700K | 90 | 50 | 418 | 449 | 147 | 8.5 |
| P4111-006-0304-P3090-X | 3000K | 90 | 50 | 439 | 472 | 154 | 8.5 |
| P4111-006-0304-P3590-X | 3500K | 90 | 50 | 447 | 481 | 157 | 8.5 |
| P4111-006-0304-P4090-X | 4000K | 90 | 50 | 460 | 494 | 161 | 8.5 |
| P4111-006-0304-P4590-X | 4500K | 90 | 50 | 463 | 497 | 163 | 8.5 |
| P4111-006-0304-P5090-X | 5000K | 90 | 50 | 466 | 501 | 164 | 8.5 |
| P4111-006-0304-P5790-X | 5700K | 90 | 50 | 466 | 501 | 164 | 8.5 |
| P4111-006-0304-P6590-X | 6500K | 90 | 50 | 460 | 494 | 161 | 8.5 |
| P4111-006-0304-P2797-X | 2700K | 97 | 90 | 355 | 382 | 125 | 8.5 |
| P4111-006-0304-P3097-X | 3000K | 97 | 90 | 380 | 409 | 134 | 8.5 |
| P4111-006-0304-P3597-X | 3500K | 97 | 85 | 393 | 422 | 138 | 8.5 |
| P4111-006-0304-P4097-X | 4000K | 97 | 85 | 405 | 436 | 142 | 8.5 |
| P4111-006-0304-P4595-X | 4500K | 95 | 80 | 393 | 423 | 137 | 8.5 |
| P4111-006-0304-P5095-X | 5000K | 95 | 80 | 396 | 426 | 139 | 8.5 |
