| 产品型号 Product Code |
色温 CCT |
显指 CRI |
光通量 Luminous Flux （lm） |
光效 Efficacy （lm/w） |
电压 Voltage （V） |
||
|---|---|---|---|---|---|---|---|
| Ra | R9 | ||||||
| Min. | Min. | Min. | Typ. | Typ. | Typ. | ||
| P4111-006-1201-P2280-X | 2200K | 80 | 0 | 419 | 451 | 147 | 34.0 |
| P4111-006-1201-P2580-X | 2500K | 80 | 0 | 435 | 468 | 153 | 34.0 |
| P4111-006-1201-P2780-X | 2700K | 80 | 0 | 451 | 485 | 158 | 34.0 |
| P4111-006-1201-P3080-X | 3000K | 80 | 0 | 476 | 512 | 167 | 34.0 |
| P4111-006-1201-P3580-X | 3500K | 80 | 0 | 488 | 525 | 172 | 34.0 |
| P4111-006-1201-P4080-X | 4000K | 80 | 0 | 501 | 539 | 176 | 34.0 |
| P4111-006-1201-P4580-X | 4500K | 80 | 0 | 504 | 542 | 177 | 34.0 |
| P4111-006-1201-P5080-X | 5000K | 80 | 0 | 507 | 545 | 178 | 34.0 |
| P4111-006-1201-P5780-X | 5700K | 80 | 0 | 507 | 545 | 178 | 34.0 |
| P4111-006-1201-P6580-X | 6500K | 80 | 0 | 501 | 539 | 176 | 34.0 |
| P4111-006-1201-P2290-X | 2200K | 90 | 50 | 354 | 380 | 124 | 34.0 |
| P4111-006-1201-P2590-X | 2500K | 90 | 50 | 369 | 397 | 130 | 34.0 |
| P4111-006-1201-P2790-X | 2700K | 90 | 50 | 385 | 414 | 135 | 34.0 |
| P4111-006-1201-P3090-X | 3000K | 90 | 50 | 413 | 444 | 145 | 34.0 |
| P4111-006-1201-P3590-X | 3500K | 90 | 50 | 419 | 451 | 147 | 34.0 |
| P4111-006-1201-P4090-X | 4000K | 90 | 50 | 426 | 458 | 150 | 34.0 |
| P4111-006-1201-P4590-X | 4500K | 90 | 50 | 430 | 463 | 151 | 34.0 |
| P4111-006-1201-P5090-X | 5000K | 90 | 50 | 435 | 468 | 153 | 34.0 |
| P4111-006-1201-P5790-X | 5700K | 90 | 50 | 435 | 468 | 153 | 34.0 |
| P4111-006-1201-P6590-X | 6500K | 90 | 50 | 429 | 461 | 151 | 34.0 |
| P4111-006-1201-P2797-X | 2700K | 97 | 90 | 300 | 323 | 106 | 34.0 |
| P4111-006-1201-P3097-X | 3000K | 97 | 90 | 325 | 350 | 114 | 34.0 |
| P4111-006-1201-P3597-X | 3500K | 97 | 85 | 338 | 363 | 119 | 34.0 |
| P4111-006-1201-P4097-X | 4000K | 97 | 85 | 350 | 377 | 123 | 34.0 |
| P4111-006-1201-P4595-X | 4500K | 95 | 80 | 366 | 393 | 129 | 34.0 |
| P4111-006-1201-P5095-X | 5000K | 95 | 80 | 370 | 398 | 130 | 34.0 |
